Mobile refrigeration system air conditioning tube, designed for buses and off-highway equipment, with excellent performance characteristics. Its air conditioning system can operate in extreme temperatures, ranging from -40°C to 135°C, ensuring a comfortable ride in any climate. The air conditioning pipe is made of high-quality materials, has excellent high temperature and low temperature resistance, and has good corrosion resistance and stability. In addition, its compact design is easy to install and maintain, providing efficient and reliable cooling and heating functions for mobile refrigeration systems. In long-distance travel or bad weather conditions, the air conditioning pipe performs particularly well, providing stable temperature control for passengers and equipment, and is an ideal choice for mobile refrigeration equipment.

Specifications			Outer diameter	Working pressure		Burst pressure		Bending radius	Length	Weight
dash	inch	mm	mm	Bar	psi	Bar	psi	mm	M/roll	kg/m
-3	3/16"	4.8	13.0	35	508	150	2176	90	50-100	0.21
-4	1/4"	6.4	14.2	35	508	150	2176	100	50-100	0.22
-5	5/16"	7.9	17.2	35	508	150	2176	115	50-100	0.32
-6	3/8"	9.7	19.3	35	508	150	2176	125	50-100	0.37
-8	1/2"	12.7	23.4	35	508	150	2176	180	50-100	0.53
-10	5/8"	16.0	27.3	35	508	150	2176	205	50-100	0.68
-12	3/4"	19.0	28.7	35	508	150	2176	240	50	0.60
-14	7/8"	22.0	31.2	35	508	150	2176	280	50	0.71
-18	1.1/8"	28.0	38.0	35	508	150	2176	350	40	0.93
-22	1.3/8"	35.0	45.0	35	508	150	2176	480	40	0.98

The product manufacturing meets or exceeds the requirements of SAE, DIN, GB, GOST or other industries, and has the properties of high pressure resistance, high humidity resistance, softness, high pulse pressure, no head expansion, light weight, long life, etc. The main fields and equipment involved include ships, vehicles, construction machinery, mining, agriculture, construction, environmental protection, wind power, transportation, petroleum, electric power, food, chemical industry, metallurgy, injection molding, etc...
