Suitable for the heating system in the cooling circulation system of the vehicle,can customize the bent pipe and the special-shaped pipe; Temperature Range: -40°C ~+180°C

The radiator heater pipe is an important part of the automobile heat dissipation system. Its main function is to transfer the heat generated by the engine to the radiator through the pipe, so that the outside air can take the heat away and ensure the normal operating temperature of the engine. This pipe is usually connected to the water outlet of the engine and directs hot water to the radiator core, causing air to carry heat away through the radiator. In addition, it also helps to adjust the temperature in the car to ensure comfortable driving. Its material is mostly high temperature plastic or metal, compact structure, easy to install. When damaged, it needs to be repaired or replaced in time to ensure the normal operation of the heat dissipation system and maintain the best working condition of the engine. In short, the radiator heater plays a key role in the vehicle cooling and temperature control system.

Specifications			Outer diameter	Working pressure		Burst pressure		Bending radius	Length	Weight
dash	inch	mm	mm	Bar	psi	Bar	psi	mm	M/roll	kg/m
-2	5/32"	4	9.1	35	500	140	2000	40	50-100	0.12
-3	3/16"	4.8	10.3	35	500	140	2000	40	50-100	0.15
-4	1/4"	6.4	13	28	400	112	1600	45	50-100	0.16
-5	5/16"	7.9	14.6	28	400	112	1600	65	50-100	0.19
-6	3/8"	9.7	16.5	28	400	112	1600	80	50-100	0.24
-8	1/2"	12.7	20.4	28	400	112	1600	100	50-100	0.32
-10	5/8"	16.0	23.6	24	350	96	1440	160	50	0.39
-12	3/4"	19.1	27.6	21	305	84	1218	190	50	0.52
-14	7/8"	22.0	31.0	20	300	80	1200	220	50	0.60
-16	1"	25.4	34.5	17.5	250	75	1000	250	50	0.66
-20	1.1/4"	31.8	42.5	15	215	60	860	320	40	1.05
-24	1.1/2"	38.1	48.5	12	175	48	750	420	40	1.25
-28	1.3/4"	45.0	55.0	10	145	40	580	500	40	1.45
-32	2"	50.8	62.0	10	145	40	580	630	40	1.65
-38	2.3/8"	60	70.0	10	145	40	580	700	20	1.82

The product manufacturing meets or exceeds the requirements of SAE, DIN, GB, GOST or other industries, and has the properties of high pressure resistance, high humidity resistance, softness, high pulse pressure, no head expansion, light weight, long life, etc. The main fields and equipment involved include ships, vehicles, construction machinery, mining, agriculture, construction, environmental protection, wind power, transportation, petroleum, electric power, food, chemical industry, metallurgy, injection molding, etc...
