Transporting liquefied petroleum gas, natural gas, hydrogen, nitrogen, etc; Temperature Range: -40°C ~+100°C; Appearance: Smooth or wrapped; Color: Black or multiple colors

The fabric woven gas pipe is specially designed for transporting liquefied petroleum gas LPG, natural gas CNG, etc. It can operate safely in extreme temperature environments, and the temperature range covers from minus 40 degrees Celsius to one hundred degrees Celsius. Exquisite appearance, can choose smooth or cloth design, both beautiful and practical. In terms of color, black and a variety of color options are available to meet individual needs. The pipe uses high-quality fabric weaving technology to ensure strength and durability, while maintaining flexibility, easy to install and use. Whether for domestic, industrial or commercial use, this gas pipe is the ideal choice for safety, reliability and efficiency. Its carrying medium is diverse, including hydrogen, nitrogen, etc., to meet a variety of gas transport needs. The length can be customized according to actual needs to provide users with a convenient experience.

Specifications			Outer diameter	Working pressure		Burst pressure		Bending radius	Length	Weight
dash	inch	mm	mm	Bar	psi	Bar	psi	mm	m/roll	kg/m
-3	3/16"	4.8	12.0	35	500	140	2000	50	50-100	0.12
-4	1/4"	6.4	13.0	28	400	112	1600	65	50-100	0.13
-5	5/16"	7.9	14.6	28	400	112	1600	75	50-100	0.16
-6	3/8"	9.7	16.5	28	400	112	1600	75	50-100	0.21
-8	1/2"	12.7	20.4	28	400	112	1600	100	50-100	0.27
-10	5/8"	16.0	23.6	24	350	96	1400	125	50-100	0.33
-12	3/4"	19.1	27.6	21	300	84	1200	150	50	0.45
-16	1"	25.4	34.5	17.5	250	70	1000	180	50	0.57
-20	1.1/4"	31.8	42.5	15	215	60	860	240	40	0.95
-22	1.3/8"	35.0	46.0	13.5	200	54	800	300	40	1.05
-24	1.1/2"	38.1	48.5	12	175	48	700	360	40	1.15
-32	2"	50.8	62.0	10	145	40	580	500	40	1.55

The product manufacturing meets or exceeds the requirements of SAE, DIN, GB, GOST or other industries, and has the properties of high pressure resistance, high humidity resistance, softness, high pulse pressure, no head expansion, light weight, long life, etc. The main fields and equipment involved include ships, vehicles, construction machinery, mining, agriculture, construction, environmental protection, wind power, transportation, petroleum, electric power, food, chemical industry, metallurgy, injection molding, etc...
