Suitable for extreme temperature conditions, using petroleum-based hydraulic fluids; Temperature Range: -30°C ~+135°C; Appearance: Smooth or wrapped; Color: Black or blue

This high temperature resistant hydraulic hose is specially designed for extreme temperature conditions and can operate stably within a temperature difference of -30°C to 135°C. It uses high quality petroleum-based hydraulic oil to ensure smooth and efficient transmission. In terms of appearance, this hose has both smooth and cloth patterns to meet different needs. In terms of color, the combination of black and blue is not only beautiful, but also helps to improve recognition in different working environments. Its tough and durable characteristics make it widely used in heavy industry, automobile, machinery and other fields. Whether it is a high or low temperature environment, this hydraulic hose can maintain excellent performance and ensure the continuity and safety of work. To choose it is to choose the guarantee of quality and trust. The length can be customized according to customer needs to meet the needs of different application scenarios.

Specifications			Outer diameter	Working pressure		Burst pressure		Bending radius	Length	Weight
dash	inch	mm	mm	Bar	psi	Bar	psi	mm	m/roll	kg/m
-3	3/16"	4.8	13.3	415	6000	1660	24000	90	50-100	0.32
-4	1/4"	6.4	15.0	400	5800	1600	23200	100	50-100	0.38
-5	5/16"	7.9	16.5	350	5000	1400	20000	115	50-100	0.44
-6	3/8"	9.7	18.9	330	4800	1320	19200	125	50-100	0.54
-8	1/2"	12.7	22.0	275	4000	1100	16000	180	50-100	0.70
-10	5/8"	16.0	25.5	250	3600	1000	14400	205	50-100	0.80
-12	3/4"	19.1	29.3	215	3100	860	12400	240	50	0.95
-14	7/8"	22.2	32.0	190	2740	760	10960	280	50	1.13
-16	1"	25.4	35.5	165	2400	660	9600	300	50	1.32
-18	1.1/8"	28.6	39.9	145	2088	580	8350	400	40	1.63
-20	1.1/4"	31.8	44.3	125	1800	500	7200	420	40	1.95
-24	1.1/2"	38.1	50.3	90	1300	360	5200	500	40	2.20
-29	1.13/16"	46.0	57.0	70	1000	280	4000	600	40	2.49
-32	2"	50.8	63.8	80	1160	320	4640	630	40	2.78

The product manufacturing meets or exceeds the requirements of SAE, DIN, GB, GOST or other industries, and has the properties of high pressure resistance, high humidity resistance, softness, high pulse pressure, no head expansion, light weight, long life, etc. The main fields and equipment involved include ships, vehicles, construction machinery, mining, agriculture, construction, environmental protection, wind power, transportation, petroleum, electric power, food, chemical industry, metallurgy, injection molding, etc...
